RH18L

1-2 Ton Mini EX

The RHINOCEROS RH18 Crawler Excavator delivers powerful performance in a compact design, making it the perfect choice for jobs in tight spaces. Weighing just 3,946 lbs, this machine features a robust backhoe and a 0.95 cu ft bucket, ideal for digging, trenching, and material handling. Its reliable KUBOTA D902 engine provides 15.8 hp and impressive torque for consistent, fuel-efficient operation. The advanced hydraulic system, with a TAIFENG piston pump and 2,900 psi work pressure, ensures smooth, responsive controls and a fast 10.5 gal/min flow rate. With a maximum digging depth of 7 ft 8 in and a reach of 12 ft 9 in, the RH18 handles demanding tasks with ease. Durable rubber tracks offer excellent traction while minimizing ground disturbance, and high-quality components like the EATON swing motor and EDDIE traveling motor guarantee long-lasting reliability. Compact dimensions and a tight swing radius make maneuvering simple, while ample hydraulic and fuel tank capacities support extended work sessions. The RH18 is a dependable, versatile excavator built for construction, landscaping, and utility projects.

MSRP Starting At $19,000

FIND DEALER

Technical Data

Specifications

a	Wheel base: 4 ft 0.4 in (1,230 mm)
b	Track length: 5 ft 2.6 in (1,590 mm)
c	Upper chassis ground clearance: 18.6 in (473 mm)
d	Counterweight turning radius: 2 ft 7.1 in (790 mm)
e	Chassis width: 3 ft 3 in / 4 ft 0.8 in (990/1,240 mm)
f	Track width: 9.1 in (230 mm)
g	Track height: 14.2 in (360 mm)
h	Transportation length: 12 ft 0.8 in (3,655 mm)
i	Height of seat to ground: 5 ft 9.3 in (1,760 mm)
j	Total height: 8 ft 1 in (2,467 mm)
k	Boom swing-left: 12.8 in (325 mm)
l	Boom swing-right: 18.9 in (479 mm)
m	Basic length: 3 ft 10.9 in (1,165 mm)

Pump type	Piston pump
Pump (manufacturer)	TAIFENG
Valve	TAIFENG
Swing motor	EATON
Traveling motor	EDDIE
Cylinder	SUQINGGE
Work pressure	2,900 psi (20 MPa)
Flow rate	10.5 gal/min (39.6 L/min)
Hydraulic oil tank capacity	4.04 gal (15.3 L)

Operating weight	3,946 lbs (1,790 kg)
Standard bucket capacity	0.95 cu ft (0.027 m³)
Engine displacement	0.24 gal (0.898 L)
Hydraulic oil tank capacity	4.04 gal (15.3 L)
Fuel tank capacity	4.76 gal (18 L)

A	Max. digging radius on ground: 12 ft 9 in (3,908 mm)
B	Max. digging radius: 12 ft 2 in (3,700 mm)
C	Max. digging depth: 7 ft 8 in (2,346 mm)
D	Max. digging height: 11 ft 7 in (3,529 mm)
E	Max. dumping height: 8 ft 1 in (2,481 mm)
F	Max. vertical digging depth: 5 ft 9 in (1,761 mm)
G	Min. swing radius: 5 ft 0.5 in (1,537 mm)
H	Max. blade lifting height: 10.7 in (271 mm)
Max. blade lifting depth	7.3 in (186 mm)

Model No.	KUBOTA D902
Displacement	0.24 gal (0.898 L)
Rated power	15.8 hp (11.8 kW) at 2,300 rpm
Max. torque	37.8 lb-ft (51.3 N·m) at 1,800 rpm

Engine model	KUBOTA D902
Displacement	0.24 gal (0.898 L)
Rated power	15.8 hp (11.8 kW) at 2,300 rpm
Max. torque	37.8 lb-ft (51.3 N·m) at 1,800 rpm
Max. travel speed	1.37/1.06 mph (2.2/1.7 km/h)
Swing speed	8.5 rpm
Max. gradeability	30%
Work pressure	2,900 psi (20 MPa)
Flow rate	10.5 gal/min (39.6 L/min)
Standard bucket capacity	0.95 cu ft (0.027 m³)
Max. digging radius on ground	12 ft 9 in (3,908 mm)
Max. digging radius	12 ft 2 in (3,700 mm)
Max. digging depth	7 ft 8 in (2,346 mm)
Max. vertical digging depth	5 ft 9 in (1,761 mm)
Max. digging height	11 ft 7 in (3,529 mm)
Max. dumping height	8 ft 1 in (2,481 mm)
Min. swing radius	5 ft 0.5 in (1,537 mm)
Max. blade lifting height	10.7 in (271 mm)
Max. blade lifting depth	7.3 in (186 mm)
